Descriptions

The system consists of sealed feed, dedicated sludge dryer, sealed discharge, exhaust gas treatment and other systems. The system achieves safe operation control by controlling combustible components, temperature, pressure, and oxygen. It has high applicability to sludge containing organic solvents such as oil and is currently one of the safest sludge drying processes in China.

Suitable for oily sludge (oil content ≤ 10%), coal chemical sludge, and other sludge containing combustible organic solvents, electroplating sludge, and chemical sludge.

Technical advantages

Compact structure and small footprint: processing tons of mud per day takes up 3-6m2.

Innovative design, high thermal efficiency: large adjustment range (10-20% oil content), low energy consumption.

Combination configuration, stable and durable: stable operation, small displacement.

Good safety and wide applicability: fully enclosed design, safe and environmentally friendly.

Reduction effect

The moisture content range of the incoming sludge is 70-90%;

The moisture content range of finished dry sludge is 30-40%;

Sludge reduction can reach 78%;

24-hour continuous operation

Safety control mode (optional)
